HIGH QUALITY METAL STAMPINGS

Cost effective, high quality and efficiently manufactured metal stampings is a core competence of Frank Dudley Ltd.



Frank Dudley’s metal stamping capabilities

Frank Dudley Ltd (FDL) has invested heavily in our equipment, people and processes so that today we offer a full turn-key service from design, toolmaking, manufacture assembly and just-in-time delivery to demanding sectors such as automotive and aerospace.

FDL has over 35 presses to suit your requirement ranging from 25T– 630T on both our coil fed progression presses and also our tandem manually operated presses. Production rates are up to 80,000 pieces per day. Our manufacturing plant occupies 57,000 square feet and houses a range of ancillary processes to support your bespoke assembly requirements, all of which are maintained to industry benchmark standards.

We can offer metal pressings from laser cut blanks with secondary operations if required.



THE FRANK DUDLEY DIFFERENCE

FDL offers outstanding customer service and delivery

Frank Dudley Limited (FDL) is proud to be chosen by many UK and global companies for the manufacture of metal stampings and welded assemblies of the very highest standard. These customers – some of whom have been our partners for 40 years – know that FDL offers outstanding customer care and efficient turnaround of high quality components and competitive pricing.

We want our customers to experience the most cost effective and efficient manufacturing solution, so that FDL is their metal stampings manufacturing partner of choice. To do this we are committed to a consistently high quality metal stamping service and work closely with customers through every stage of the design, manufacturing and delivery process.

Custom metal pressings and stampings

At the heart of our single operation metal stamping expertise lies our range of ‘C’ frame and large bed power presses. These range in capacity from 25 tonnes-630 tonnes, offering our customers total flexibility when it comes to choosing the press that best suits their needs.

Our efficient tooling solutions offer complete flexibility, value for money and the highest level of quality. We offer customers a wide choice of metal forming operations, materials, finishes and production volume. Due to our wide range of capacities, operations can be carried out individually, in pairs for handled parts and to ensure we keep our competitive edge, we will also gang or stage certain operations.

FDL understand that the quality of our services and components are only ever as good as the machinery and people we invest in. All our staff are trained to NVQ Business Improvement Techniques (BiT) Level 1. Fifteen of our 70 staff have completed an apprenticeship or are in formal training and we have four employees taking an apprenticeship. Our machines are regularly maintained and new equipment includes a new brightware manufacturing cell.

We would be delighted to tell you more about our pressing and stamping techniques and how economical these services can be for your business, no matter which industry you operate in.

Examples of operations FDL currently produce:

  • Forming, piercing, coining, marking and drawing
  • Blanking or cropping from strip, coil or blanks

We can produce metal stampings in the following materials:

  • Stainless steel, mild steel and aluminium 0.5mm to 15mm thick

We also offer a wide range of finishes for your components, including but not limited to:

  • Surface – vibro debur, chemical black or polished
  • Plating – zinc, barrel zinc, chrome or black chrome
  • Paint – powder or e-coat

PRODUCTION VOLUMES

FDL can manufacture any volume from 50 components per batch to 15,000 components per week. If you need lower volumes, just let us know and we will do our utmost to accommodate your needs. We can offer metal stampings from laser cut blanks with secondary operations if required.

CORE MANUFACTURING CAPABILITIES

FDL offers core manufacturing capabilities that include:
  • Pressing & Stamping
  • Deep drawn component
  • Component assembly
  • Tool making
  • Design for manufacture
  • Welded assembly

Our progression and single action pressing and stamping lines are equipped with modern systems to protect the materials from possible damage and any potential cross contamination with other materials

SECONDARY OPERATIONS

Our secondary operations include:

  • Metal pressings / stampings
  • Deep drawn components
  • Assembled components
  • Tool making
  • Drilling, tapping and reaming
  • Spot and projection welding
  • CO2 welding – manual and robotic

Speak to our team today for more information about our metal pressings and how we can help you to get the best return on your investment with us.

***Click here for a full list of FDL’s manufacturing standards, customers and key account longevity, training qualifications, average employee services ***

CONTACT US

For any metal pressing and stampings product enquiry, please call a member of our team today on tel: 0121 452 8500. See our stainless steel, aluminum and brightware pages to understand our capabilities in stainless steel.
